| VANE IMPELLER ANEMOMETER | |||
| Type : BA-16 | |||
| Brand : Trotec (Germany) | |||
| Specification : | |||
| 1). Speed | |||
| Measuring range | : | 1.00 - 30.00 m/s; 196 - 5,900 ft/min; 3.6 - 108.0 km/h | |
| Resolution | : | 0.01 m/s, 1 ft/min, 0.1 km/h | |
| Accuracy | : | ± 3 % ± 0.2 m/s, ± 3 % ± 40 ft/min, ± 3 % ± 0.8 km/h | |
| 2). Flow | |||
| Measuring range | : | 0 - 999.9 m³/min (CMM) | |
| Resolution | : | 0.1 CMM | |
| 3). Functions | : | °C / °F, m/s, ft/min, m³/min (CMM), km/h, mph, kn | |
| : | Minimum and maximum value indicator | ||
| : | Hold-function | ||
| : | illuminated display | ||
| : | Automatic switch-off | ||
| 4). Temperature | |||
| Measuring range | : | '-10.0 bis +60.0 °C (+140.0 up to +140.0 °F) | |
| Resolution | : | 0.1 °C (0.1 °F) | |
| Accuracy | : | ± 1.5 °C (± 3.0 °F) | |
| 5). Dimensions without probe | 165 x 54 x 32 mm (l x w x h) | ||
| Power supply | : | 9 V IEC 6LR61 | |
| Weight | : | 270 g | |
| Scope of delivery | : | Measurement device, battery, carrying case, operating manual | |
