Type : 270
Specification :
| ▪ | Frequency range | ||
| Air Conduction range | : | 0.125, 0.25, 0.5, 0.75, 1.15, 2, 3, 4, 6, 8 kHz | |
| Bone Conduction | : | 0.25, 0.5, 0.75, 1.15, 2, 3, 4, 6, 8 | |
| Frequency accuracy | : | <1% | |
| Distortion | : | <2% | |
| Test method | : | Continuous, interrupted, pulsed, warble | |
| ▪ | Output level range | ||
| Air Conduction range | : | -10 dBHL to 120 dBHL ±3dB | |
| Bone Conduction | : | -10 dBHL to 70 dBHL ±3dB | |
| Output level step | : | 2.5 / 5dB | |
| ▪ | Masking | ||
| Masking | : | Norrowband and speech weighted noise | |
| Output | : | Headphones, insert earphone or insert masker | |
| Insert masking output | : | 90dBHL max (250-4 kHz) | |
| ▪ | Speech input | : | MP3 or CD input or live speech |
| ▪ | Freefield | ||
| Output level range (FF) | : | Up to 90 dB | |
| No of loudspeaker | : | 2 | |
| ▪ | Special tests | ||
| Overthreshold tests | : | Stenger test, ABLB (Fowler), SISI | |
| ▪ | Communication | ||
| Talk over | : | Integrated or external monitor headset | |
| Talk back | : | External microphone | |
| ▪ | Data management | ||
| Internal database | : | 12 audiograms | |
| Optional printer | : | Thermal printer | |
| Data transfer | : | Via USB to Amplisuite, NOAH, | |
| OtoAccess® and other EMR system | |||
| ▪ | Physical data | ||
| Display | : | 2 lines of 24 characters | |
| Power | : | 240Vac 50-60Hz | |
| Dimensions | : | (L x W x H): 355 x 230 x 50mm | |
| Weight | : | 1540 g / 330 lbs | |
| ▪ | Safety and standard | ||
| Type | : | Audiometer Type 3BE/Type 2 | |
| Safety | : | IEC 60601-1 (plus UL, CSA & EN deviation | |
| EMC | : | IEC 60601-1-2 | |
| Performance | : | IEC 60645-1/ANSI S3.6 | |
| CE Mark | : | Complies to EU Medical Device | |
| Regulation (MDR 2017/745) | |||
| ▪ | Complete unit | : | Main units + Audiocups |
| : | Standard audiometric headset | ||
| : | Bone conduction headset | ||
| : | Patient response switch | ||
| : | Audiogram cards (50) | ||
| : | Power supply with country adaptors | ||
| : | Carry case | ||
| : | USB stick (manuals, audiometry module | ||
| for NOAH and Amplisuite software) |
