Type : 270+ + Audiocups
Specification :
| ▪ | Frequency range | ||
| Air Conduction range | : | 0.125, 0.25, 0.5, 0.75, 1.15, 2, 3, 4, 6, 8 kHz | |
| Bone Conduction | : | 0.25, 0.5, 0.75, 1.15, 2, 3, 4, 6, 8 | |
| Frequency accuracy | : | <1% | |
| Distortion | : | <2% | |
| Test method | : | Manual or automatic mode AC and BC | |
| Tone present | : | Continuous or interupted pulsed, warble | |
| ▪ | Output level range | ||
| Air Conduction range | : | -10 dBHL to 120 dBHL ±3dB | |
| Bone Conduction | : | -10 dBHL to 120 dBHL ±3dB | |
| Output level step | : | 1, 2, 5 dB | |
| ▪ | Masking | ||
| Masking | : | Norrowband and speech weighted noise | |
| Output | : | Headphones, insert earphone or insert masker | |
| Insert masking output | : | 90dBHL max (250-4 kHz) | |
| ▪ | Freefield | ||
| Output level range (FF) | : | Up to 90 dB | |
| No of loudspeaker | : | 2 | |
| ▪ | Special tests | ||
| Overthreshold tests | : | Stenger test, ABLB (Fowler), SISI, Tone decay (Cahart) |
|
| Simulators | : | MHA, HLS | |
| ▪ | Communication | ||
| Talk over | : | Integrated or external monitor headset | |
| Talk back | : | External microphone | |
| ▪ | Data management | ||
| Internal database | : | 10 audiograms | |
| Optional printer | : | MPT-II thermal printer | |
| Data transfer | : | Via USB to Amplisuite, NOAH, | |
| OtoAccess® and other EMR system | |||
| Languages | : | English, German, Polish | |
| ▪ | Speech Input | : | PC, tape, CD or MP3 input or live speech |
| ▪ | Safety and standard | ||
| Type | : | Audiometer Type 3BE/Type 2 | |
| Safety | : | IEC 60601-1 (plus UL, CSA & EN deviation | |
| EMC | : | IEC 60601-1-2 | |
| Performance | : | IEC 60645-1/ANSI S3.6 | |
| CE Mark | : | Complies to EU Medical Device | |
| Regulation (MDR 2017/745) | |||
| ▪ | Physical data | ||
| Display | : | 2 lines of 24 characters | |
| Power | : | 100-240Vac 50-60Hz | |
| Dimensions/weight | : | (L x W x H): 259 x 374 x 90mm / 1400 g | |
| ▪ | Complete unit | : | Main unit + Audiocups |
| : | Standard audiometric headset | ||
| : | Bone conduction headset | ||
| : | Patient response switch | ||
| : | Audiogram cards (50) | ||
| : | Mains power adaptor | ||
| : | Carry case | ||
| : | USB cable (PC connection) | ||
| : | Amplisuite PC software and NOAH connection module |
